NETAPP Enterprise NVMe Solid State Drive - Model 108-00260 (X447A-R6) Product Details

1、 Product Overview

       NETAPP 108-00260 (product model X447A-R6) is an enterprise grade NVMe solid-state drive using Samsung's high-quality flash memory, with a capacity of 800GB. This product is designed specifically for the storage needs of mid to high end enterprises, achieving an excellent balance between performance, durability, and cost-effectiveness, and is suitable for business scenarios with high performance requirements.

2、 Detailed technical specifications

       Parameter Category Detailed Specification Remarks

       Basic Information

       Manufacturer Model X447A-R6 NetApp Custom Model

        NETAPP part number 108-00260 unique identification code

        Samsung Enterprise Flash Granules, a flash memory manufacturer

        Interface Protocol NVMe over PCIe 3.0

        Appearance specification 2.5 inches U.2 enterprise standard appearance

         Capacity information

         Nominal Capacity 800GB Original Capacity

          Available capacity ≈ 730GB considering system redundancy

           performance parameters

          Sequential read speed 3200 MB/s, sustained performance

          Sequential write speed of 1500 MB/s and sustained performance

          4K random read 450000 IOPS queue depth 256

          4K random write 75000 IOPS queue depth 256

         Read/write latency reading<90 μ s, write<20 μ s typical value

         Reliability parameters

          Durability level 3 DWPD daily full disk write count

         Service life 4.3 PBW lifetime write capacity

          Mean time between failures 2000000 hours

          Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. High performance architecture

         Adopting Samsung enterprise grade V-NAND flash memory

        Optimized PCIe 3.0 x4 interface

         High performance flash memory controller

         Support multi queue access

2. Enterprise level reliability

         Power outage protection: Supercapacitors protect data security

        End to end data protection: complete data verification

        Advanced ECC: Powerful Error Correction Capability

        Wear and tear balance: intelligent block management

3. Intelligent management function

        Hot swappable support: online maintenance capability

        S. M.A.R.T.: Health Status Monitoring

         Temperature Management: Dynamic Temperature Control Adjustment

         Firmware Management: Online Upgrade Function

4、 Compatibility information

         Supported NetApp systems:

         AFF A Series Full Flash Array

         FAS8000 series hybrid storage

         Supports ONTAP 9.3 and higher versions

         Physical compatibility:

         Standard 2.5-inch disc position

         Compatible with specific models of disk racks

          Support hot swappable installation

5、 Recommended application scenarios

1. Key applications for enterprises

          Medium sized database system

         virtualization platform

          enterprise application server

2. Performance sensitive applications

          Real time data processing

          Online trading system

           Business Analysis Platform

3. Mixed workloads

         Read write hybrid application

        file share service

         Collaborative platform storage
