Enterprise grade solid state drive PM1723B 7.68T U.2 NVMe PCIe 3.0 ultra large capacity data warehouse monitoring storage disk

EMC Enterprise NVMe Solid State Drive - Model 118033281 Product Detailed Description

1. Product Overview

       The EMC 118033281 (model PM1723B) is a high-performance enterprise-grade NVMe SSD with a capacity of up to 7.68TB. This product utilizes the latest 3D TLC NAND flash technology and PCIe 4.0 interface, specifically designed for high-demand workloads in  modern data centers, achieving a perfect balance between large capacity, high performance, and exceptional reliability.

II. Detailed Technical Specifications

      Parameter Category  Detailed Specifications  Notes

      Basic Information

      EMC Part Number 118033281 Primary Identification Code

     Disk Model: PM1723B

     Physical Disk Identifier

      Interface Protocol: NVMe over PCIe 4.0 (Latest Interface Standard)

 Form Factor: 2.5-inch U.2 (SFF-8639)

     Enterprise Standard

     Capacity information

      Nominal Capacity 7.68TB  Original Capacity

      Available capacity ≈7.0TB after accounting for system redundancy

      Performance parameters

      Sequential read speed: 7,000 MB/s PCIe 4.0 performance

     Sequential Write Speed: 4,200 MB/s

     Sustained Write Performance

      4K Random Read 1,400,000 IOPS High Queue Depth

     4K Random Write  300,000 IOPS  Random Write Performance

     Read and Write Latency

     Read <65μs, Write <10μs

     Ultra-Low Latency

      Reliability parameters

      Durability Rating: 3 DWPD (Drive Writes Per Day)

       Service Life: 42 PBW (Total Data Written)

III. Core Technologies and Features

1. High-performance Architecture Design

     PCIe 4.0 x4 interface delivers double the bandwidth of PCIe 3.0

      Supports NVMe 1.4 standard features

      Multi-namespace Management

      Advanced Queue Management Mechanism

2. Enterprise-level reliability assurance

       Full-path power-off protection: Supercapacitor ensures data safety

        End-to-end Data Protection: Complete Data Integrity from Host to Flash

       Advanced ECC Error Correction: LDPC Error Correction Technology

       Intelligent Wear Leveling: Dynamic Wear Management Algorithm

3. Intelligent Management Function

      Hot-swap support: online maintenance and replacement

      S.M.A.R.T. Enhanced Monitoring: Predictive Failure Analysis

       Temperature Intelligent Regulation: Dynamic Thermal Throttling

        Remote Management Interface: Supports the NVMe-MI standard

IV. Compatibility Information

       Supported Dell EMC Systems:

       PowerMax Series: PowerMax 2000, 8000

      Unity Series: Unity XT

       PowerEdge MX series

      Support for VMware vSAN Ready Nodes

      Operating System Support:

      Windows Server 2019/2022

      Red Hat Enterprise Linux 7/8

       VMware ESXi 7.0 or higher

      SUSE Linux Enterprise Server

V. Recommended Application Scenarios

1. Key Business of the Enterprise

      Large databases (Oracle Exadata, SAP HANA)

       Enterprise Resource Planning System

      Critical Business Application Storage

2. Cloud Data Center

       Software-Defined Storage Solution

      Converged infrastructure

       Cloud-native application storage

3. High-Performance Computing

       Artificial Intelligence and Machine Learning

       Real-time data analysis

       High-performance computing cluster

4. Virtualization Environment

      Large-scale VDI deployment

      Server virtualization

       Container persistent storage
