118033280 3.84TB NVMe PowerMAX 2000 / 8000 Vt 005052696 MZWLL3T8HAJQ-00AC3 PM1723Bb

EMC Enterprise NVMe Solid State Drive - Model 118033280 Product Detailed Description

I. Product Overview

     The EMC 118033280 (Part No.: 005053079/005053504, Drive Model PM1723B) is a high-performance enterprise-grade NVMe SSD with a capacity of 3.84TB. This product utilizes advanced 3D TLC NAND flash technology and a PCIe 4.0 interface, specifically designed for modern enterprise mission-critical workloads, achieving an optimal balance between performance, capacity, and cost-effectiveness.

 II. Detailed Technical Specifications

       Parameter Category Detail Specifications

       Basic Information

       EMC Part Number 118033280

       Replacement part number 005053079 / 005053504

       Platter Model: PM1723B

       Interface Protocol: NVMe over PCIe 4.0

       Form Factor: 2.5-inch U.2

       Capacity information

       Nominal Capacity: 3.84TB

      Available capacity ≈3.5TB

     Performance parameters

     Sequential read speed 6,800 MB/s

      Sequential write speed: 4,000 MB/s

      4K Random Read 1,200,000 IOPS

     4K Random Write 280,000 IOPS

     Read and Write Latency

    Read <70μs, Write <12μs

    Reliability parameters

     Durability Rating 5 DWPD

     Service life: 35 PBW

     Mean Time Between Failures: 2,500,000 hours

     Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture

     PCIe 4.0 x4 interface, offering a rate of 16 GT/s

     Supports all features of the NVMe 1.4 standard

      Optimized Parallel Processing Architecture

       Dynamic Power Management

2. Enterprise-level Reliability

      Full-path power-off protection: Super capacitor protection mechanism

       End-to-end data integrity: Complete CRC checksum protection

       Advanced LDPC Error Correction: Powerful Error Correction Capability

       Intelligent Wear Leveling: Dynamic Block Management Algorithm

3. Intelligent Management Function

        Hot-swapping support: Online maintenance capability

       Enhanced Monitoring: S.M.A.R.T. Attribute Monitoring

       Temperature Management: Dynamic Thermal Throttling

        Remote Management: NVMe-MI Management Interface

4、 Compatibility information

        Supported Dell EMC Systems:

       PowerMax Series: PowerMax 2000/8000

       Unity XT series

      PowerEdge MX Series

      VxRail hyper fusion system

       Operating system support:

      Windows Server 2019/2022

      Red Hat Enterprise Linux 7/8/9

      VMware ESXi 6.7/7.0/8.0

      SUSE Linux Enterprise Server 15

5、 Recommended application scenarios

1. Key applications for enterprises

       Large scale database systems (Oracle, SQL Server)

      SAP HANA in memory computing

        Enterprise Resource Planning System

2. Virtualization environment

       Large scale VDI deployment

      Server virtualization platform

       Containerized application storage

3. Cloud data center

       Software defined storage

        Hybrid cloud storage solution

        Cloud native application storage

4. Data analysis

        Real time data processing

        Business Intelligence Analysis

       AI/machine learning workloads

6、 Summary of Product Advantages

       performance advantage

       Excellent read and write throughput

       Ultra low latency response

       Stable service quality

       Capacity advantage

       Optimized storage density

       Efficient capacity utilization

       Good scalability

      management advantage

       Deep integration with Dell EMC management tools

       Simplified operation and maintenance management

       Intelligent monitoring and warning

7、 Environmental specifications

       Parameter specifications

       Working temperature: 0 ° C to 55 ° C

       Storage temperature -40 ° C to 70 ° C

      Working humidity 8% to 90% non condensing

      Working altitude of 3000 meters

       Typical power consumption 10-12W

       Maximum power consumption 18W

        Anti vibration 5.0 Grms (5-800 Hz)
