Enterprise grade solid state drive 7.68TB U.2 NVMe SSD 118000748-01 ultra large capacity data center level storage solution

EMC Enterprise NVMe Solid State Drive - Model 118000748-01 Product Details

1、 Product Overview

        EMC 118000748-01 is a product that uses Intel technology ® The latest 3D NAND flash technology for ultra large capacity enterprise NVMe solid-state drives, with a capacity of up to 7.68TB. This product is based on PCIe 4.0 interface and NVMe protocol, designed specifically for the extreme performance requirements of modern data centers, setting a new industry benchmark in storage density, performance, and reliability.

2、 Detailed technical specifications

       Detailed specifications of parameter categories

       Basic Information

       EMC part number 118000748-01

       Flash technology from Intel ®  144 layer 3D TLC NAND

       Interface protocol NVMe 1.4 over PCIe 4.0

       Appearance specification 2.5 inches U.2 (15mm thickness)

       Capacity information

       Nominal capacity 7.68TB

      User available capacity ≈ 7.0TB

      performance parameters

       Sequential read speed 7200 MB/s

      Sequential write speed 4500 MB/s

      4K random read 1600000 IOPS

     4K random write 350000 IOPS

     Read/write delay: Read<65 μ s, write<8 μ s

     Reliability parameters

     Durability level 3 DWPD

     Service life 84 PBW

      Mean time between failures 2500000 hours

      Unrepairable error rate<1e-17

       Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. Intel  Innovative Flash Memory Technology

        Adopting 144 layer 3D TLC NAND

       Innovative floating gate technology

       High density storage unit design

       Optimized charge retention capability

2. Enterprise level reliability assurance

       Full path power-off protection: enhanced supercapacitor array

       End to end data protection: complete data path protection

      Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction

      Intelligent Health Management: Real time Health Status Monitoring

3. Intelligent management function

      Hot swappable support: Compliant with NVMe hot swappable standards

      Health status monitoring: Telemetry 2.0 telemetry

       Intelligent temperature control: Multi zone temperature sensor

      Remote management: NVMe MI 1.2 management interface

4、 Compatibility information

       Supported Dell EMC Systems:

      PowerMax 2500/8500 Full Flash Array

       PowerEdge MX series modular servers

       Unity XT 680F/880F hybrid storage

       VxRail P-series hyper fusion system

      Software environment support:

       VMware HANA 7.0 U3 and above

       Windows Server 2022

        Red Hat Enterprise Linux 8.5 and above

       SUSE Linux Enterprise Server 15 SP3

5、 Recommended application scenarios

1. Ultra large scale data center

      Hyper converged infrastructure

     Software defined storage platform

      Cloud service provider infrastructure

2. Key business of the enterprise

     Ultra large database system

      Enterprise level data warehouse

       Key business application storage

3. Artificial Intelligence and Big Data

       AI training platform storage

      Machine learning workloads

       Big data analysis platform

4. High performance computing

       Scientific research computation

       Financial modeling analysis

       4K/8K video processing
