For DELL EMC POWERSTORE SSD 1.92TB NVME 2.5` 005052920 005053702 005053076 005053077 005053703 118000838 005052919 005052920 SSD

EMC Enterprise NVMe Solid State Drive - Model 118000838 Product Detailed Description

1. Product Overview

      The EMC 118000838 (model number PM1733) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes advanced 3D TLC NAND flash technology, featuring a PCIe 4.0 interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads. It serves as an ideal storage solution for building modern data centers.

II. Detailed Technical Specifications

      Parameter Category Detail Specifications

      Basic Information

       EMC Part Number 118000838

       Disk Model: PM1733

       Flash memory type: 3D TLC NAND

       Interface Protocol: NVMe over PCIe 4.0

       Form factor: 2.5-inch U.2

      Capacity information

      Nominal Capacity: 1.92TB

     Available user capacity ≈1.75TB

       Performance parameters

      Sequential read speed: 6,500 MB/s

      Sequential write speed: 3,200 MB/s

       4K Random Read 900,000 IOPS

       4K Random Write 200,000 IOPS

       Read and Write Latency: Read <75μs, Write <15μs

      Reliability parameters

      Durability Rating: 5 DWPD

     Service life: 17.5 PBW

     Mean Time Between Failures: 2,500,000 hours

     Annual failure rate: 0.44%

      Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture design

       PCIe 4.0 x4 interface, delivering high bandwidth

      Supports NVMe 1.4 standard features

      Optimized Flash Controller

       Low-latency architecture design

2. Enterprise-level Reliability

        Power Failure Protection Mechanism: Super Capacitor Data Protection

       End-to-end data protection: comprehensive data integrity verification

       Advanced Error Correction: LDPC Error Correction Technology

       Intelligent Wear Leveling: Dynamic Block Management

3. Smart Management Function

       Hot-swap support: Online maintenance capability

       Health Status Monitoring: Enhanced S.M.A.R.T

       Temperature Management: Dynamic Temperature Control Adjustment

        Remote Management: NVMe-MI Management Interface

IV. Compatibility Information

       Supported Dell EMC Systems:

      PowerMax 2500/8500 Series

      Unity XT 380F/480F/680F/880F

      PowerEdge MX Series Servers

       VxRail P Series/V Series

      Operating System Support:

      VMware vSphere 7.0 or later

       Windows Server 2019/2022

       Red Hat Enterprise Linux 8/9

      SUSE Linux Enterprise Server 15

V. Recommended Application Scenarios

1. Key Enterprise Applications

      Medium-sized database system

      Virtualization platform storage

      Enterprise application server

2. Cloud Computing Environment

       Private cloud storage infrastructure

       Hybrid Cloud Storage Solution

      Cloud-native application storage

3. Data Analysis

       Real-time data processing

      Business Intelligence Analytics

      Machine learning workloads

4. Virtualization Deployment

      Virtual Desktop Infrastructure (VDI)

      Server virtualization

      Container platform storage
