EMC Enterprise NVMe Solid State Drive - Model 118000207-02 Product Details

1、 Product Overview

      EMC 118000207-02 (using Toshiba flash technology) is a high-performance enterprise NVMe solid-state drive with a capacity of 3.84TB. The product is based on Toshiba's advanced 3D TLC NAND flash technology, combined with PCIe interface and NVMe protocol, providing excellent storage performance and reliability for enterprise workloads, and is a key storage component of modern data centers.

2、 Detailed technical specifications

     Detailed specifications of parameter categories

     Basic Information

     EMC part number 118000207-02

     Toshiba 3D TLC NAND Flash Technology

      Interface Protocol NVMe over PCIe 3.0

      Appearance specification 2.5 inches U.2

      Capacity information

      Nominal capacity 3.84TB

       User available capacity ≈ 3.5TB

        performance parameters

       Sequential read speed 3300 MB/s

       Sequential write speed 1900 MB/s

       4K random read 650000 IOPS

       4K random write 160000 IOPS

       Read/write delay: Read<85 μ s, write<16 μ s

       Reliability parameters

       Durability level 3 DWPD

       Service life 21 PBW

       Mean time between failures 2000000 hours

      Annual failure rate 0.44%

      Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

     1. Toshiba Flash Memory Technology Innovation

     Adopting Toshiba BiCS FLASH 3D TLC NAND

     64 layer stacked architecture

     Innovative Memory Hole Process Technology

     High reliability storage unit design

2. Enterprise level reliability

       Power outage protection mechanism: complete data protection circuit

      End to end data protection: full path data integrity verification

       Advanced Error Correction Technology: LDPC Error Correction

       Intelligent Health Management: Real time Flash Health Monitoring

3. Intelligent management function

       Hot swappable support: online maintenance capability

       Health status monitoring: S.M.A.R.T. attribute monitoring

       Temperature Management: Dynamic Temperature Control Adjustment

       Remote management: Standard management interface support

4、 Compatibility information

       Supported Dell EMC Systems:

       Unity series storage array

       PowerEdge series servers

       VxRail hyper fusion system

       PowerMax All Flash Array

       Operating system support:

       VMware HANA 6.7 and above

       Windows Server 2016/2019

      Red Hat Enterprise Linux 7/8

       SUSE Linux Enterprise Server 12/15

5、 Recommended application scenarios

1. Key business of the enterprise

       Large scale database system

      Virtualization platform storage

      Enterprise Application Server

2. Cloud computing environment

      Private cloud storage infrastructure

      Hybrid cloud storage solution

      Cloud native application storage

3. Data analysis

      Business Intelligence Analysis

      Big data processing

      Real time data processing

4. Data Protection

      Backup storage acceleration layer

      Disaster recovery storage

       Data hierarchical storage

6、 Summary of Product Advantages

       performance advantage

      Balanced read and write performance

      Stable low latency

     Good IOPS performance

      Reliability advantage

     Toshiba's high-quality flash memory technology

     Enterprise level durability design

     Comprehensive data protection

     cost advantage

     Optimized total cost of ownership

     High energy efficiency design

      Long term operational economy

7、 Environmental specifications

      Parameter specifications

      Working temperature: 0 ° C to 55 ° C

      Storage temperature -40 ° C to 70 ° C

        Working humidity 8% to 90% non condensing

         Working altitude of 3000 meters

        Typical power consumption 10-12W

        Maximum power consumption 18W

        Anti vibration 5.0 Grms (5-800 Hz)
