Enterprise Server SSD Unity 7.68T EMC 2.5" 7.68TB 12Gb/s SAS SSD MZILT7T6HMLA-000C3 118000634

EMC Enterprise NVMe Solid State Drive - Model 118000634 Product Details

1、 Product Overview

       EMC 118000634 (replacement part number: 005052557, disk body model PM1643) is a high-capacity enterprise NVMe solid state drive with a capacity of up to 7.68TB. The product uses advanced 3D TLC NAND flash technology, based on PCIe 3.0 interface and  NVMe protocol, to provide excellent storage density and performance for enterprise workloads, making it an ideal storage solution for modern large-scale data centers.

2、 Detailed technical specifications

     Detailed specifications of parameter categories

     Basic Information

      EMC part number 118000634

      Alternative part number 005052557

      Disk model PM1643

      Flash technology 3D TLC NAND

      Interface protocol NVMe 1.3 over PCIe 3.0

      Appearance specification 2.5 inches U.2 (15mm thickness)

     Capacity information

     Nominal capacity 7.68TB

     User available capacity ≈ 7.0TB

     performance parameters

    Sequential read speed 3200 MB/s

    Sequential write speed of 2000 MB/s

    4K random read 600000 IOPS

    4K random write 150000 IOPS

    Read/write delay: Read<90 μ s, write<20 μ s

3、 Core Technologies and Characteristics

    1. High density storage architecture

    PCIe 3.0 x4 interface

   High density 3D TLC NAND flash memory

   Optimized storage space management

   Support large capacity data storage

2. Enterprise level reliability design

   Power outage protection mechanism: supercapacitor data protection

   End to end data protection: complete data integrity verification

   Advanced Error Correction: LDPC Error Correction Technology

   Intelligent Health Monitoring: Real time Flash Health Management

3. Intelligent management function

   Hot swappable support: online maintenance capability

  Health status monitoring: Enhanced S.M.A.R.T

  Temperature management: Multi zone temperature monitoring

  Remote management: Standard management interface support

4、 Compatibility information

   Supported Dell EMC Systems:

   Unity XT 380F/480F/680F/880F

   PowerEdge MX series servers

   VxRail hyper fusion system

   PowerMax All Flash Array

   Operating system support:

   VMware HANA 7.0 and above

   Windows Server 2019/2022

   Red Hat Enterprise Linux 8/9

   SUSE Linux Enterprise Server 15

5、 Recommended application scenarios

1. Large scale data storage

   Ultra large database system

   Data warehouse storage

   Archive data storage

2. Cloud computing environment

   Cloud storage infrastructure

   Big data analysis platform

   Cloud native application storage

3. Virtualization environment

    Large scale virtualization deployment

    Virtual Desktop Infrastructure (VDI)

   Container platform persistent storage

4. Media and Entertainment

   4K/8K video editing and storage

   Media Content Asset Management

   Streaming media service platform

6、 Summary of Product Advantages

    Capacity advantage

    Industry leading storage density

    Optimized spatial efficiency

    Reduce overall cost of ownership

    performance advantage

   Stable read-write performance

   Good IOPS performance

   Suitable for large capacity workloads

   Reliability advantage

   Enterprise level durability design

   A comprehensive data protection mechanism

   Long life cycle guarantee

7、 Environmental specifications

   Parameter specifications

   Working temperature: 0 ° C to 55 ° C

   Storage temperature -40 ° C to 70 ° C

   Working humidity 8% to 90% non condensing

   Working altitude of 3000 meters

   Typical power consumption 12-14W

    Maximum power consumption 20W

     Anti vibration 5.0 Grms (5-800 Hz)
