NETAPP Enterprise NVMe Solid State Drive - Model 108-00856 (X4010A-PM1733) Product Details

1、 Product Overview

       NETAPP 108-00856 (product model X4010A, disk body model PM1733) is a high-performance enterprise grade NVMe solid-state drive with a capacity of 1.92TB. The product uses advanced 3D TLC NAND flash technology and is designed specifically for read intensive workloads, achieving an excellent balance between performance, durability, and cost-effectiveness.

2、 Technical specifications

       Detailed specifications of parameter categories

       Basic Parameters

       Manufacturer model X4010A

       NETAPP part number 108-00856

       Disk model PM1733

       Interface type NVMe over PCIe

       Appearance specification 2.5 inches U.2

       performance parameters

       Nominal capacity 1.92TB

        Available capacity 1.75TB (based on RAID configuration)

       Sequential read speed up to 3400 MB/s

       Sequential write speed up to 1500 MB/s

       4K random read up to 450000 IOPS

      4K random write up to 75000 IOPS

      Delay read<85 μ s, write<18 μ s

     Reliability parameters

      Durability level 3 DWPD

      Life indicator 10.5 PBW (lifetime write capacity)

      MTBF 2, 000000 hours

      Warranty period of 5 years or achieving durability indicators

3、 Core technical features

1. Optimized read performance

       Adopting PCIe 3.0/4.0 x4 interface

      Specially optimized for read operations

      Design of Low Power High Performance Controller

       Supports NVMe 1.3/1.4 standards

2. Enterprise level reliability

        Typical power consumption: 8-10W

        Maximum power consumption: 14W

        Integrated power-off protection function

        End to end data path protection

3. Intelligent management function

        Support hot plug operation

        Online firmware upgrade capability

        Advanced S.M.A.R.T. monitoring

        Temperature adaptive performance adjustment

4、 Compatibility information

        Supported system models:

         AFF A220, A250, A400 series

         FAS500f, FAS8300 series

         Supports ONTAP 9.5 and higher versions

          AFF A series controller

         Supports standard 2.5-inch disk slots

5、 Application scenarios

1. Read intensive applications

          Virtual Desktop Infrastructure (VDI)

          Content Delivery Network (CDN)

          Data analysis and report query

          Web server storage

2. Enterprise level applications

          Database Read Copy

          Application server storage

          file share service

          Email server storage

3. Cloud service scenarios

          Virtual machine image storage

         Container persistent storage

          Backup and archive storage

          Development and testing environment
