Enterprise grade solid state drive 1.92TB U.2 NVMe SSD 118000043-01 005051102 database disk storage expansion

EMC Enterprise NVMe Solid State Drive - Model 118000043-01 Product Detailed Description

1. Product Overview

       The EMC 118000043-01 (Part Number: 005051102) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. Utilizing advanced 3D TLC NAND flash technology, this product is based on the PCIe interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads, making it  suitable for various data center application scenarios.

II. Detailed Technical Specifications

        Parameter Category  Detailed Specifications

       Basic Information

       EMC Part Number 118000043-01

       Replacement Part Number 005051102

       Flash memory type: 3D TLC NAND

       Interface Protocol: NVMe over PCIe

       Physical dimensions: 2.5-inch U.2

      Capacity information

      Nominal Capacity 1.92TB

      Available user capacity ≈1.75TB

      Performance parameters

      Sequential read speed: 3,200 MB/s

      Sequential write speed: 1,800 MB/s

      4K Random Read: 600,000 IOPS

     4K Random Write 150,000 IOPS

     Read and Write Latency

     Read <85μs, Write <15μs

     Reliability parameters

     Durability Level 3 DWPD

     Service life 10.5 PBW

     Mean Time Between Failures: 2,000,000 hours

     Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture

       PCIe 3.0 x4 interface

       NVMe Optimized Protocol Stack

      High-performance flash memory controller

      Support for multiple namespaces

2. Enterprise-level Reliability

       Power Failure Protection Mechanism: Data Integrity Assurance

        End-to-end Data Protection: Comprehensive Verification Mechanism

       Advanced Error Correction: LDPC Error Correction Technology

       Smart Wear Leveling: Extend Service Life

3. Smart Management Function

       Hot-swapping support: Online maintenance capability

       Health Status Monitoring: S.M.A.R.T. Attributes

       Temperature Management: Dynamic Temperature Control Adjustment

       Remote Management: Standard Management Interface

4、 Compatibility information

       Supported Dell EMC Systems:

       Unity series storage array

       PowerEdge series servers

       VxRail hyper fusion system

        PowerMax All Flash Array

       Operating system support:

       VMware HANA 6.7 and above

       Windows Server 2016/2019

       Red Hat Enterprise Linux 7/8

      SUSE Linux Enterprise Server 12/15

5、 Recommended application scenarios

1. General enterprise workloads

        Virtualization platform storage

       Medium sized database applications

       File sharing service

2. Cloud infrastructure

       Virtual machine image storage

       Container persistent storage

       Development and testing environment

3. Commercial applications

       Email server storage

       Web application storage

       Collaborative platform storage
