EMC Enterprise NVMe Solid State Drive - Model 118000588-03 Product Details
1、 Product Overview
EMC 118000588-03 (using Hitachi flash technology) is a high-performance enterprise grade NVMe solid state drive with a capacity of 3.84TB. The product is based on Hitachi's high-quality flash technology and is designed specifically for the high demand workloads of modern data centers. It achieves outstanding balance in performance, capacity, and reliability, making it an ideal storage solution for critical business applications in enterprises.
2、 Detailed technical specifications
Detailed specifications of parameter categories
Basic Information
EMC part number 118000588-03
Hitachi 3D TLC NAND Flash Technology
Interface Protocol NVMe over PCIe 4.0
Appearance specification 2.5 inches U.2
Capacity information
Nominal capacity 3.84TB
Available capacity ≈ 3.5TB
performance parameters
Sequential read speed 6800 MB/s
Sequential write speed 3900 MB/s
4K random read 1100000 IOPS
4K random write 260000 IOPS
Read/write delay: Read<75 μ s, write<15 μ s
Reliability parameters
Durability level 5 DWPD
Service life 35 PBW
Mean time between failures 2500000 hours
Annual failure rate 0.44%
Warranty Policy 5-year Limited Warranty
3、 Core Technologies and Characteristics
1. Hitachi Flash Memory Technology Innovation
Adopting Hitachi's advanced 3D TLC NAND technology
PCIe 4.0 x4 interface, providing high bandwidth
Optimized flash controller architecture
Supports NVMe 1.4 standard features
2. Enterprise level reliability engineering
Multi layer power-off protection: a complete capacitor backup system
End to end data integrity: full path data protection
Advanced Error Correction: Powerful LDPC Error Correction Capability
Intelligent Wear Management: Dynamic Balance Algorithm
3. Intelligent management function
Hot swappable support: online maintenance capability
Predictive Health Monitoring: Enhanced S.M.A.R.T
Intelligent temperature control: multi zone temperature monitoring
Remote management support: NVMe MI standard interface
4、 Compatibility information
Supported Dell EMC Systems:
PowerMax series: 2000/8000/2500/8500
Unity XT series: 380F/480F/680F/880F
PowerEdge MX series servers
VxRail hyper fusion system
Software environment support:
VMware HANA 7.0 and above
Windows Server 2019/2022
Red Hat Enterprise Linux 8/9
SUSE Linux Enterprise Server 15
5、 Recommended application scenarios
1. Key business of the enterprise
Large scale database systems (Oracle, SQL Server)
SAP HANA In Memory Computing Platform
Enterprise Resource Planning System
2. Virtualization environment
Large scale virtualization deployment
Virtual Desktop Infrastructure (VDI)
Containerized platform storage
3. Data analysis platform
Real time data processing
Business Intelligence Analysis
Artificial Intelligence/Machine Learning
4. Cloud service infrastructure
Private cloud storage platform
Hybrid cloud storage solution
Cloud native application storage
6、 Summary of Product Advantages
performance advantage
Excellent read and write throughput
Stable low latency performance
Excellent IOPS performance
Capacity advantage
High storage density design
Optimized capacity efficiency
Good scalability
Reliability advantage
Hitachi's high-quality flash memory technology
Enterprise level durability design
A comprehensive data protection mechanism
7、 Environmental specifications
Parameter specifications
Working temperature: 0 ° C to 55 ° C
Storage temperature -40 ° C to 70 ° C
Working humidity 8% to 90% non condensing
Working altitude 3050 meters
Typical power consumption 11-13W
Maximum power consumption 20W
Anti vibration 5.0 Grms (5-800 Hz)
