EMC Enterprise NVMe Solid State Drive - Model 118000630 Product Details

1、 Product Overview

     EMC 118000630 (disk body model PM1643) is a high-performance enterprise grade NVMe solid-state drive with a capacity of 1.92TB. The product uses advanced 3D TLC NAND flash technology, based on PCIe interface and NVMe protocol, to provide reliable performance for enterprise workloads, making it an ideal choice for building modern storage infrastructure.

2、 Detailed technical specifications

      Detailed specifications of parameter categories

     Basic Information

     EMC part number 118000630

      Disk model PM1643

      Flash Memory Type: 3D TLC NAND

     Interface Protocol NVMe over PCIe 3.0

     Appearance specification 2.5 inches U.2

     Capacity information

     Nominal capacity 1.92TB

    User available capacity ≈ 1.75TB

    performance parameters

   Sequential read speed 3200 MB/s

    Sequential write speed 1800 MB/s

   4K random read 600000 IOPS

   4K random write 150000 IOPS

    Read/write delay: Read<90 μ s, write<20 μ s

    Reliability parameters

    Durability level 3 DWPD

   Service life 10.5 PBW

    Mean time between failures 2000000 hours

    Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. High performance architecture

    PCIe 3.0 x4 interface

    NVMe optimized protocol stack

    High performance flash memory controller

    Support multiple namespaces

2. Enterprise level reliability

     Power outage protection mechanism: data integrity guarantee

     End to end data protection: complete verification mechanism

    Advanced Error Correction: LDPC Error Correction Technology

    Intelligent wear balance: extending service life

3. Intelligent management function

       Hot swappable support: online maintenance capability

      Health status monitoring: S.M.A.R.T. attribute

     Temperature Management: Dynamic Temperature Control Adjustment

     Remote Management: Standard Management Interface

4、 Compatibility information

     Supported Dell EMC Systems:

    Unity series storage array

   PowerEdge series servers

    VxRail hyper fusion system

    Specific models of PowerMax systems

    Operating system support:

     VMware HANA 6.7 and above

     Windows Server 2016/2019

     Red Hat Enterprise Linux 7/8

     SUSE Linux Enterprise Server 12/15

5、 Recommended application scenarios

1. General enterprise workloads

     Virtualization platform storage

    Medium sized database applications

     File sharing service

2. Cloud infrastructure

      Virtual machine image storage

      Container persistent storage

      Development and testing environment

3. Commercial applications

     Email server storage

    Web application storage

    Collaborative platform storage

4. Data Protection

     Backup storage acceleration layer

    Disaster recovery storage

    Data hierarchical storage

6、 Summary of Product Advantages

      performance advantage

     Balanced read and write performance

     Stable low latency

     Good IOPS performance

     Reliability advantage

     Enterprise level durability design

     Comprehensive data protection

    Long life cycle

     cost advantage

    Optimized total cost of ownership

     High energy efficiency design

     Low maintenance cost

7、 Environmental specifications

     Parameter specifications

    Working temperature: 0 ° C to 55 ° C

    Storage temperature -40 ° C to 70 ° C

     Working humidity 8% to 90% non condensing

      Typical power consumption of 8-10W

      Maximum power consumption 15W

      Anti vibration meets enterprise level standards
