HPE P02434-004 (PM1643) 7.68TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

         HPE P02434-004 (disk body model PM1643) is a high-performance enterprise NVMe solid-state drive that uses HPE's self-developed enterprise level solution. This hard drive is designed specifically for enterprise critical business systems that require high-performance and large capacity storage, achieving the best balance between performance, capacity, and reliability. It is suitable for application scenarios such as virtualization, databases, and cloud computing.

1. Core features and specifications

       Capacity specification: 7.68TB

       (Adopting intelligent capacity management technology and optimizing OP configuration to the optimal state)

       Interface protocol: NVMe 1.3 over PCIe 3.0 x4

       Appearance specification: 2.5 inches U.2 (SFF-8639)

        Performance performance:

       Continuous reading speed: up to 3400 MB/s

       Continuous write speed: up to 2400 MB/s

        Random read IOPS: up to 800000 (4K)

        Random write IOPS: up to 130000 (4K)

        Durability index:

        DWPD: 1.2 (5-year warranty period)

        TBW：16.8PB

        MTBF: 2.5 million hours

        Flash Memory Type: 3D eTLC NAND

       (Using enterprise grade enhanced TLC flash memory to provide excellent durability)

2. Advanced features

       Intelligent power management:

       Multi level power consumption state management, power efficiency increased by 25%

       Integrated Advanced Power Failure Protection (PLP) Circuit

       Data Protection:

       End to end data path protection

       Enhanced ECC Error Correction Algorithm

       RAID level data protection function

        Performance optimization:

        Intelligent pre reading and caching algorithm

        QoS Service Quality Control

       Adaptive read-write scheduling

       Security management:

        AES 256 bit hardware encryption

        TCG Enterprise Security Standard

        Instant secure erase function

3. Applicable scenarios

        Enterprise level database:

        Oracle RAC Cluster Database

        SQL Server Large Database

        SAP HANA In Memory Database

         Virtualization platform:

         VMware HANA hyper converged architecture

         Microsoft Hyper-V Virtualization Platform

         Containerized application storage

         Cloud computing:

         Public cloud block storage service

         Private cloud storage resource pool

         Hybrid cloud storage solution

         Big data analysis:

         Real time data analysis platform

        Machine learning training data storage

        Streaming data processing and storage

4. Compatibility information

       Support platform:

       HPE ProLiant DL360/380 Gen10

       HPE ProLiant DL325/385 Gen10+

       HPE Apollo 2000/4000 Series

       HPE Synergy 480/660 Series

       System requirements:

       UEFI 2.5 or higher version

       NVMe 1.3 and above protocol support

       Supports PCIe 3.0 x4 interface

       Management tools:

       HPE iLO 5 Advanced Management Suite

       HPE OneView Unified Management Platform

       HPE InfoSight Predictive Analysis
