Enterprise grade solid state drive PM1643 3.84TB U.2 NVMe PCIe high-speed read and write compatible with Dell R740 R740xd

HPE P02435-009 (PM1643) 3.84TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

       HPE P02435-009 (disk body model PM1643) is a high-performance enterprise NVMe solid-state drive that uses HPE's self-developed enterprise level solution. This hard drive is designed specifically for enterprise critical business systems that require high-performance storage, achieving the best balance between performance, capacity, and reliability, and is suitable for application scenarios such as databases, virtualization, and cloud computing.

1. Core features and specifications

       Capacity specification: 3.84TB

        (Adopting intelligent capacity management technology and optimizing OP configuration to the optimal state)

          Interface protocol: NVMe 1.3 over PCIe 3.0 x4

         Appearance specification: 2.5 inches U.2 (SFF-8639)

         Performance performance:

         Continuous reading speed: up to 3200 MB/s

         Continuous write speed: up to 2100 MB/s

         Random read IOPS: up to 600000 (4K)

         Random write IOPS: up to 120000 (4K)

         Durability index:

         DWPD: 1.2 (5-year warranty period)

         TBW：8.4PB

         MTBF: 2.5 million hours

        Flash Memory Type: 3D eTLC NAND

        (Using enterprise grade enhanced TLC flash memory to provide excellent durability)

2. Advanced features

       Intelligent power management:

      Multi level power consumption state management

       Integrated Advanced Power Failure Protection (PLP) Circuit

       Power efficiency increased by 20%

       Data Protection:

       End to end data path protection

       Enhanced ECC Error Correction Algorithm

       RAID level data protection function

      Performance optimization:

      Intelligent pre reading and caching algorithm

      QoS Service Quality Control

      Adaptive read-write scheduling

      Thermal management:

       Multi point temperature monitoring

        Dynamic temperature control regulation

       Overheating protection mechanism

3. Applicable scenarios

       Enterprise level database:

       Oracle database system

       sql server database

       MySQL cluster deployment

       Virtualization platform:

       VMware HANA environment

       Microsoft Hyper-V Platform

      Containerized application storage

      Cloud computing:

       Private cloud storage resource pool

      Hybrid cloud storage solution

      Cloud native application storage

      Big data analysis:

      Real time data processing

      Data warehouse storage

      Business Intelligence Analysis

4. Compatibility information

      Support platform:

      HPE ProLiant DL360 Gen10

      HPE ProLiant DL380 Gen10

      HPE Apollo 4200 System

      HPE Synergy 480 System

      System requirements:

      UEFI 2.4 or higher version

      NVMe 1.3 protocol support

      PCIe 3.0 x4 interface

      Management tools:

      HPE iLO 5 Management Suite

      HPE OneView Management Platform

      HPE InfoSight analysis tool
