Enterprise grade solid-state drive PM1633a 3.84TB U.2 NVMe PCIe high-speed read and write compatible with HPE DL380 Gen10

HPE 874430-003 (PM1633a) 3.84TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

        HPE 874430-003 (disk body model PM1633a) is a high-performance enterprise grade NVMe solid-state drive that uses HPE's self-developed enterprise grade solution. This hard drive is designed specifically for enterprise critical business systems that require high-performance storage, achieving the best balance between performance, capacity, and reliability, and is suitable for application scenarios such as databases, virtualization, and cloud computing.

       1. Core features and specifications

       Capacity specification: 3.84TB

       (Adopting intelligent capacity management technology and optimizing reserved space)

       Interface protocol: NVMe 1.3 over PCIe 3.0 x4

       Appearance specification: 2.5 inches U.2 (SFF-8639)

       Performance performance:

      Continuous reading speed: up to 3200 MB/s

      Continuous write speed: up to 2100 MB/s

      Random read IOPS: up to 620000 (4K)

      Random write IOPS: up to 125000 (4K)

      Durability index:

      DWPD: 1.2 (5-year warranty period)

      TBW：8.4PB

       MTBF: 2.5 million hours

        Flash Memory Type: 3D eTLC NAND

       (Using enterprise grade enhanced TLC flash memory)

        2. Advanced features

      Intelligent power management:

      Multi level power consumption state management

      Integrated Power Failure Protection (PLP) Circuit

      Power efficiency increased by 25%

       Data Protection:

       End to end data path protection

       Enhanced ECC Error Correction Algorithm

        RAID data protection mechanism

       Performance optimization:

        Intelligent read ahead caching technology

        QoS Service Quality Control

        Adaptive read-write scheduling

       Thermal management:

       Real time temperature monitoring

       Dynamic temperature control regulation

       Overheating protection mechanism

       3. Applicable scenarios

       Enterprise level database:

       Oracle RAC cluster

       sql server database

        SAP HANA system

        Virtualization platform:

        VMware vSphere

        Microsoft Hyper-V

        Containerized platform storage

         Cloud computing:

         Private cloud storage pool

         Hybrid cloud solution

         Cloud native applications

         Big data analysis:

         Real time data processing

         Data warehouse storage

         Business Intelligence Analysis

        4. Compatibility information

        Support platform:

       HPE ProLiant DL360 Gen10

       HPE ProLiant DL380 Gen10

       HPE Apollo 4200 System

       HPE Synergy 480 System

      System requirements:

       UEFI 2.4 or higher version

       NVMe 1.3 protocol support

        PCIe 3.0 x4 interface

        Management tools:

        HPE iLO 5 Management Suite

        HPE OneView Management Platform

        HPE InfoSight analysis tool
