Original enterprise grade NVMe SSD 9.6TB PCIe 4.0 Model 02CL185, shelf number 02YC417, including original pallet

Product Overview

1.Core Title

Original All Flash Storage Solution | 9.6TB NVMe PCIe 4.0 Enterprise Solid State Drive with Professional Cooling System (Complete Component Number: 02CL185-02YC417) - Provides Ultimate Performance Storage Guarantee for Data Centers

2.Core advantages

Ultimate Performance Performance

Adopting NVMe PCIe 4.0 interface protocol, the sequential read speed reaches up to 7000 MB/s, the sequential write speed reaches 4500 MB/s, and the random read/write performance exceeds 1.6M IOPS, meeting the most demanding performance requirements

intelligent temperature control system

Equipped with original heat dissipation bracket (02YC417), adopting active heat dissipation technology, built-in intelligent temperature control fan, ensuring optimal temperature maintenance under full load operation

OEM Quality

Specially designed for IBM FlashSystem optimization, ensuring perfect compatibility with IBM storage systems through rigorous quality testing by IBM

Ultra large storage capacity

9.6TB ultra large capacity, using 3D TLC NAND flash technology, providing excellent storage density and performance

Enterprise level reliability

Supports 7 × 24-hour uninterrupted operation, with an annual write capacity of 3 DWPD and a warranty life of 5 years or 52.5 PBW

3.Technical specifications

Detailed specifications of parameter categories

Hard drive model 02CL185

Bracket model 02YC417

Storage capacity 9.6TB

Interface standard NVMe PCIe 4.0 x4

Appearance specification 2.5 inches U.2

Flash Memory Type: 3D TLC NAND

Includes NVMe drive body and original heat dissipation bracket (02YC417)

Read and write performance: Sequential read: 7000 MB/s | Sequential write: 4500 MB/s

Durability index 3 DWPD (5 years/52.5PBW)

Compatible with IBM FlashSystem 5200/7200/9200/9500

4.Compatible system

Perfect compatibility platform:

FlashSystem 5200

FlashSystem 7200

FlashSystem 9200

FlashSystem 9500

DS8900F

Storage Virtualize 8.5 and above versions

5.Application scenarios

Enterprise level key applications:

Artificial Intelligence Platform - Supports large-scale AI training and inference workloads

Real time data analysis - real-time applications such as financial transactions and IoT data analysis

Virtualization Infrastructure - Enterprise level Virtualization and Private Cloud Platforms

High performance databases - key databases such as Oracle Exadata and SAP HANA

Medical Imaging Storage - PACS Medical Imaging Storage and Processing System

Media Processing -4K/8K Video Editing and Rendering Workflow

6.Quality Assurance

100% original components, providing genuine verification

Pass 96 hour high-temperature aging test

Provide a complete SMART health status report

quality assurance

Professional technical support services

Support machine validation testing

7.Installation requirements

system requirements

Requires support for IBM Storage Virtualize 8.5 or higher versions

Firmware Version

Suggest upgrading to the latest IBM system firmware version

environmental conditions

Operating temperature: 5°C to 40°C

Storage temperature: -40°C to 70°C

Humidity: 8% to 90% non condensing

8.Service Support

Professional technical consultation - providing complete technical specifications and compatibility guidance

Installation and configuration support - provide detailed installation and configuration documentation

Batch purchase discount - supports enterprise level batch purchase needs

Quick response service -7 × 24-hour professional technical support

Spare parts guarantee - providing fast spare parts replacement services
